Product Description Important Note on Regulations for Fluorinated Gases IN ITALY** In accordance with Regulation (EU) No. 517/2014 and d.P.R. n. 146/2018, equipment containing non-hermetically sealed fluorinated gases can only be sold if installed by a certified company. By law, every sale must be recorded in the fluorinated gas database, including a statement from the buyer guaranteeing compliance with regulations. Therefore, before completing the order, it will be necessary to provide this mandatory declaration. Technical Features Internal Units 1) Model : Catalog Code Internal Unit : 1x JSGNW20 Power : 7000 Btu Nominal Cooling Power : 2.05 kW Nominal Heating Power : 2.15 kW Airflow : 600 m3/h Sound Power : 52 dB(A) Liquid Pipe Diameter : 6.35 mm (1/4") Gas Pipe Diameter : 9.52 mm (3/8") Internal Unit Dimensions : 792x292x201 mm Internal Unit Weight : 8 Kg Wi-Fi optional (Air Connect) 2) Model : Catalog Code Internal Unit : 2x JSGNW25 Power : 9000 Btu Nominal Cooling Power : 2.55 kW Nominal Heating Power : 2.65 kW Airflow : 600 m3/h Sound Power : 53 dB(A) Liquid Pipe Diameter : 6.35 mm (1/4") Gas Pipe Diameter : 9.52 mm (3/8") Internal Unit Dimensions : 792x292x201 mm Internal Unit Weight : 8 Kg Wi-Fi optional (Air Connect) External Unit Model : Catalog Code External Unit : LSGT60-3M Max Internal Units : up to 3 internal units Energy Efficiency : SEER : 6.5 (W/W) SCOP : 4.3 (W/W) Energy Efficiency Class (Cooling) : A++ Energy Efficiency Class (Heating) : A+ Performance : Cooling Capacity : 6.20 kW Heating Capacity : 6.60 kW Standard Cooling Absorption : 1.89 kW Standard Heating Absorption : 1.77 kW Sound Power Level : 65 dB(A) Features : Power Supply (V/Hz/Φ) : 220~240/50/1 Gas : R-32 Liquid Pipe Diameter : 6.35 mm (1/4") Gas Pipe Diameter : 9.52 mm (3/8") Guaranteed Temperature Range : - Cooling : -10 ~ +46 °C - Heating : -15° ~ 24°C Dimensions : External Unit Dimensions (LxHxD) : 834x655x328 mm External Unit Weight : 44 Kg BAXI Astra New matte white and modern design Totally new, minimal and elegant design with matte white surfaces. The front panel has a strongly vertical cut that makes the design harmonious and exclusive. Structure of the new Baxi Astra Lower connections It is possible to wall mount the internal unit before connecting the pipes, without having to disassemble the entire cover; there is also no need to incline the unit to make the connections. This reduces installation times. Baxi Astra fins is equipped with a double series of vertical and horizontal fins, with leaf-shaped fins for a uniform airflow distribution. Knobs instead of closing screws Instead of traditional screws, there are closing knobs for dismantling the plastic cover Total control of the air conditioner Easy and intuitive comfort management Comfort management takes place locally thanks to the standard remote control with LCD display and complete double keyboard with quick menu on the surface. Rich set of usable functions Smart comfort with Air Connect comfort at your fingertips with your smartphone The Air Connect App and the WI-FI module allow remote control of Baxi Astra air conditioners. The WI-FI module in the Baxi Astra range is made up of a USB Plug & Play device that is extremely easy to install. Air Connect is the application that allows you to have full control of the temperature and comfort of your home, at any time and from anywhere. For the Baxi Astra range, the WI-FI module is available as an accessory. Therefore, after installing the WI-FI module and downloading the App, you can communicate with your Baxi air conditioner directly from your Smartphone and Tablet devices (iOS and Android). With a simple touch, you can: turn on/off the air conditioner, set operating modes, fan speed, vertical and horizontal fin oscillation, active functions, timer, etc. Air Connect means convenience and ease of use: No visual impact: the WI-FI module is inserted in the dedicated housing behind the front panel of the air conditioner Easy and intuitive hourly programming that allows for a combination of comfort and high energy savings Ability to control multiple devices with the same App, in the case of Multi Split air conditioners (Dual Split, Trial Split, etc.) equipped with the WI-FI module All remote control functions are available on your device, such as: Turbo, Sleep, iClean, etc WI-FI module package The package contains: physical WI-FI module, manual and warranty certificates Terms of use This application is capable of managing more than one device (air conditioner) as long as they are Baxi air conditioners, equipped with the appropriate WI-FI module. Cutting-edge technology DC inverter technology, managing air delivery based on the real needs of the environment, ensures optimized consumption and noise reduction thanks to: Internal DC Fan External DC Fan DC Compressor Machine controller The best synthesis of functionality and performance Quiet The Baxi Astra air conditioners are designed for highly quiet operation (up to 20 dBA max) to ensure quality comfort in the environment where we stay. Product Warranty: All products sold on our website are new and packaged. The warranty on this item is 24 months from the date of purchase. Technical Data Sheet weight: 75.0 kg cooling energy class: A++ heating energy class: A+ gas: R-32 brand: BAXI model: Astra 7+9+9 60 btu power: 7000+9000+9000 heating area m2: 20/20/25
